Name: 12m Hot-Dip Galvanized Octagonal Mid-Hinged Street Light Pole
Brand: Jiangsu milky way steel poles co.,ltd
SKU: Palo per lampione stradale ottagonale con cerniera media da 12 m zincato a caldo
Price: 545.00 USD
Availability: InStock

Caratteristiche Galleria Descrizione di prodotto Richieda una citazione

Caratteristiche

Specificazioni

Tolleranza della dimensione: + - 2%

Resistenza al vento: 3-500 km/h

Materiale: GR50 GR65 S500 S355

Altezza: 12m

Saldatura: Saldatura conferma con lo standard internazionale di saldatura di CWB

verniciatura a polvere: Vernice in polvere di poliestere puro, colore opzionale

Progetto: contro il grado 8 del terremoto

Nome del prodotto: Palo per lampione stradale ottagonale con cerniera media da 12 m zincato a caldo

Evidenziare:

12m galvanized street light pole

octagonal mid-hinged light pole

hot-dip galvanized light pole

Informazioni di base

Luogo di origine: Cina

Marca: Milky Way

Certificazione: ISO//BV

Numero di modello: Palo per lampione stradale ottagonale con cerniera media da 12 m zincato a caldo

Termini di pagamento e spedizione

Imballaggi particolari: Secondo la richiesta del cliente

Tempi di consegna: solitamente 2 settimane dopo la conferma

Termini di pagamento: T/T

Capacità di alimentazione: 300 pezzi del palo al giorno

Galleria

12m Hot-Dip Galvanized Octagonal Mid-Hinged Street Light Pole

Descrizione di prodotto

Specifications:

Material:	Hot rolled steel, Q235,Q345,S235,S355,SS400,Gr 50
Yield strength of Material:	Minimum yield strength>=235n/mm2 for Q235, S235 and SS400 Minimum yield strength>=345n/mm2 for Q345 S355 and Gr 50
Pole’s height:	3m –15m
Length of one part	Within 16m once forming without slip joint
Wall thickness:	2.3mm-30mm
Pole's Shape Can be made:	Round, Polygonal, Taper Octagonal, Taper round, Round conical, Taper Square, Square.
Arm type can be made:	Single arm, Double arm, Tri-arm, Four-arm
Arm Diameter:	Diameter as 42mm, 48mm, 60mm, 76mm and etc, can fit to any diameter’s lamps.
Power:	250W to 400W
Welding	Advanced submerge-arc welding and CNC welding equipment. It has past flaw testing, internal and external double welding makes the welding beautiful in shape. It confirms with the international welding standard of CWB and AWS D 1.1
Galvanization:	Hot dip galvanization with thickness of 80-100µm average in accordance with Chinese standardGB/T 13912-2002 or American standard ASTM A123, ISO: 2626-1985.
Manufactury Capacity Per Day:	250
Wall thickness Tolerance:	+- 0.1mm from 2.3mm to 4mm. +- 0.2mm from 5mm to 20mm. +- 0.5mm from 22mm to 30mm
Painting color:	(RAL)Color card or Refer to client’s requirement
Surface treatment 1:	Black pole, Rough pole
Surface treatment 2:	Hot dip Galvanizing antirust.
Surface treatment 3:	Hot dip galvanizing with powder coating
Temperature range	-35 °C~+45 °C
Wind Speed:	Aganist wind pressure of 120Km/h to 180Km/h, it according to client’s design.
Base plate mounted	Base plate is square, octagonal or round in shape with slotted holes for anchor bolt and dimension as per customer’s requirement.
Ground mounted:	The length buried underground as per customer’s requirement.
Quality Control	According to ISO9001-2008 requirements.
Certificates	ISO9001-2008, Audited Supplier, The AAA grade certificate of goodwill
Other	Less land occupation & easy maintenance.

Description of Material:
The material we use is from Baosteel.According to the different strength request,we can use the Q235,Q345 and GR65.The strength of GR 65 is best and Q235 is lowest.
For the street light pole,we usually choose Q235 and Q345.
The good quality of steel material guarantee the good quality of the finished steel pole.

12m Hot-Dip Galvanized Octagonal Mid-Hinged Street Light Pole 0

The information to inquiry or purchase
-Steel pole height
-Dimension of the flange
-Position and dimension of the service door
-Cross arm type and length,the position to install in the steel pole
-The method to fix the cross arm(use bolt to connect or use one or two template to weld in the steel pole to install the cross arm)
-Wind speed
-Destination port
-Other.

12m Hot-Dip Galvanized Octagonal Mid-Hinged Street Light Pole 1

Installation
-Remove all the equipment on the pole during Assembly.
-Circle a sling around th epole shaft of each section.
-Fix the sling on top section to one pulley block.
-The sling on the bottom section is tightly fixed and fixed at the center of gravity.
-Make the steel pole vertical by tighten the sling of the top section.
-Fix the steel pole.
-Remove the sling.
